High Pressure brass Push Lock Misting Fittings
Customized Fabrication
High Pressure brass Push Lock Misting Fittings
Klikkon Industrial are dedicated to providing innovative products and solutions, knowledgeable support and professional service to our customers that is second to none.
Price:US $0.05 - 0.25 / Piece
Product Details
Klikkon Industrial are dedicated to providing innovative products and solutions, knowledgeable support and professional service to our customers that is second to none.
High Pressure brass Push Lock Misting Fittings
Push Lock Misting Fittings, High Pressure Misting Fittings. Outdoor Coooling Fine Misting Nozzle, Poratable Fog System Misting Nozzle:
1. Nozzle Material: Brass, SS
2. Orifice:Ruby,Ceramic,SS
3.Connection Type: Quick Slip Lock, Thread type
3.Tube size: 3/8" (9.52mm)
3. Working Pressue: 9bar to 100bar (100PSI to 1000PSI)
4. Droplet size: 5-40 Micron
5. Motor Model: 220V/50HZ, 220V/60HZ, 380/50HZ
6. Fittings Models: Nozzle, Nozzle connector, Tubing, Tubing Cutter, Water filter, Tee, Elbow, End, End Plug, Union, Male/female adapter, ball valve and water filter, etc.
Ideal Spray Professional make high quality misting system kits for cooling and misting, DIY mist cooling system simple for any applications.
We also separately supply the Fog misting nozzle, connectors, coupling, tubing and pumps.
1. Fog Misting Nozzle:
Orifice diameter: 0.1mm up to 0.5mm
Working pressure: 6-70 bar
Body material: 304SS, brass and 316ss
orifice material: SS, ceramic and ruby
Inlet thread: 10/24, 12/24, 3/16 and 1/8
2. 3/8 Connectors,Fittings and Couplings:
Material: brass and SS
Nozzle thread: 10/24,12/24UNC
Tubing Size: 3/8" (9.52mm)
Working Pressure: 70bar/1000PSI
3. Nylon Tubing & PE Tubing:
Outside diameter: 3/8"
Working Presure: 70 bar up to 120 bar
Temperature:40C.degree
4. Misting Pump Capacity:
0.3LPM, 1LPM, 2LPM,3LPM,5LPM,6LPM,7LPM,9LPM,11LPM,12LPM,15LPM,17LPM,18LPM,21LPM,25LPM
5. Pump Specification:
Pump No. : HP
Pump : Plunger
Flow rate: 3.0L/min
Pressure: 60-80bar
Power: 800w
Rpm: 1400rpm
110 / 220 Volt - 50 / 60 HZ
6.Technical data sheet for Fog Nozzles:
|
Type |
Size dia./¢ |
Thread |
Pressure |
Flow Rate |
|
FGN10 |
0.10mm/0.004" |
1/8'' |
20-70bar |
0.016-0.040L/Min |
|
FGN15 |
0.15mm/0.006" |
1/8'' |
20-70bar |
0.029-0.046L/Min |
|
FGN20 |
0.20mm/0.008" |
1/8'' |
20-70bar |
0.049-0.089L/Min |
|
FGN30 |
0.30mm/0.012" |
1/8'' |
15-70bar |
0.065-0.145L/Min |
|
FGN40 |
0.40mm/0.016" |
1/8'' |
7-70bar |
0.056-0.178L/Min |
|
FGN50 |
0.50mm/0.02" |
1/8'' |
7-70bar |
0.077-0.248L/Min |
High Pressure brass Push Lock Misting Fittings
Klikkon products are guaranteed to provide the consistently high quality and unrivalled performance that our customers demand and our product range is manufactured with comprehensive engineering and quality assurance expertise gained over many years experience in the brass fitting market.High Pressure brass Push Lock Misting Fittings
Our customers really do come first at Klikkon®. Don’t take our word for it - read through these comments from our customers and you’ll see for yourself from the results and feedback
High Pressure brass Push Lock Misting Fittings
High Pressure brass Push Lock Misting Fittings
Klikkon treat every customer with same, no matter customer are from small company or large, When customers are happy, we're happy.
If you have a design challenge, we’re ready. We have the expertise and capacity to take on your project challenge, whether the design is prototype-ready or still in the concept phase. For projects in the early phase, our engineers work closely with you to convert those ideas into final drawings. For projects further developed, we ensure part designs are optimized for full-scale production.
High Pressure brass Push Lock Misting Fittings
We pride ourselves on our Engineering staff. Their comprehensive understanding of the product development process, along with their creativity, enables them to often provide more effective answers than our customers originally anticipate.
Just tell us your idea, our technical will provide free technical support,
we will help you to make idea into true.
Flexibility? We’ve got it. We accommodate drawings in a variety of formats, including 3D models, hard copy schematics, or drawings rendered in Pro/E, SolidWorks and AutoCAD
WANT TO KNOW MORE?
ASK US A QUESTION
High Pressure brass Push Lock Misting Fittings
High Pressure brass Push Lock Misting Fittings
QUALITY CONTROL
*Recheck moulding before mass production
*Random quality test during production process
*Test HRC before and after heat treatment
*After surace finishing,check surface before packing one by one to ensure no defect exsist in finished products
*Inspect finished products,measure size,application test ect
