API flanged floating ball valves
Customized Fabrication
Klikkon Industrial are dedicated to providing innovative products and solutions, knowledgeable support and professional service to our customers that is second to none.
API flanged floating ball valves
Product Details
Our factory are good at machining,sample or drawing will be welcome.
We always try to reduce the cost to increase value for customer.
API flanged floating ball valves
Product Description
1、Technical standard:
API flanged floating ball valves
Application Field
Floating ball valves are suitable for use on various kinds of pipelines of Class 150 – Class 1500to turn on and off the pipeline medium, of which the actuators include manual, worm gear, and pneumatic or electric. Medium includes water, steam, oil, gas, nitric acid, and etc.
Specification
Note: We can also Provide other different material parts according to Customer’s request.
|
API Floating Ball Valves Standard |
||||||
|
Size |
DN15 – DN250 |
|||||
|
Design Standard |
API6D, ASMEB16.34, BS5351, API608, MSS-SP-72 |
|||||
|
Face to Face |
ASME B16.10, API6D |
|||||
|
Flange End |
ASME B16.5 |
|||||
|
BW End |
ASME B16.25 |
|||||
|
Test |
API598, API6D |
|||||
|
Fire-safe Design |
API607 |
|||||
|
Material of Parts |
||||||
|
No. |
Parts Name |
Material |
||||
|
WCB/A105 + HCr |
WCB/304 |
WCB/316 |
CF8 |
CF8M |
||
|
1 |
Body |
WCB |
WCB |
WCB |
CF8 |
CF8M |
|
2 |
Packing |
PTFE |
PTFE |
PTFE |
PTFE |
PTFE |
|
3 |
Bushing |
PTFE |
PTFE |
PTFE |
PTFE |
PTFE |
|
4 |
Packing |
ASTM A182 F6a |
ASTM A182 304 |
ASTM A182 316 |
ASTM A182 304 |
ASTM A182 304 |
|
5 |
Plate |
WCB |
WCB |
WCB |
CF8 |
CF8M |
|
6 |
Screw |
ASTM A193 B7 |
ASTM A193 B7 |
ASTM A193 B7 |
ASTM A193 B8 |
ASTM A193 B8M |
|
7 |
Stop Collar |
WCB |
|
|||
